Small in size, big in fun
With its compact body, simple controls and automatic 49cc engine, the YFZ50 is the perfect way to start out. Built for children between 6 and 9, this mini ATV is ready to provide hours of family fun.
Safety comes first, and the YFZ50 has a range of features that give parents a high degree of control. Speed can be limited by the throttle screw and rev limiter switch – and a lanyard attached to a tether switch can cut the engine instantly.
Easy to use, fun to ride and simple to maintain, the Yamaha YFZ50 is the clear choice for responsible adults – and with its YFZ450R racer-inspired styling, this mini ATV has got to be at the top of every child’s wish list!
Details
- Compact, agile ATV for children aged 6 – 9 years
- Simple to use, fun to ride and easy to maintain
- The ideal introduction to ATV riding
Yamaha quality, reliability and back up - Throttle screw for parental speed adjustment
- Switchable limiter restricts max engine speed
- Lanyard with cut-out for total parental control
- Sporty YFZ450R-inspired styling
- Low-maintenance 49cc 4-stroke air-cooled engine
Smooth CVT automatic V-belt transmission - Handlebar-mounted brake levers
- Electric start and removable kick-start
Engine
Engine type | Single cylinder, 4-stroke, air-cooled, SOHC, 2-valves |
Displacement | 49.4cc |
Bore x stroke | 39.0 mm x 41.4 mm |
Compression ratio | 8.5 : 1 |
Lubrication system | Wet sump |
Fuel system | V12 x 1 |
Ignition system | CDI |
Starter system | Electric and kick |
Transmission system | V-Belt Automatic |
Drive system | 2WD |
Final transmission | Chain |
Chassis
Front suspension system | Single A-arm, 60 mm wheel travel |
Rear suspension system | Swingarm, 51 mm wheel travel |
Front brake | Drum brake |
Rear brake | Single mechanical drum |
Front tyres | AT16x6,5-7 |
Rear tyres | N/A |
Dimensions
Overall length | 1,250 mm |
Overall width | 820 mm |
Overall height | 770 mm |
Seat height | 585 mm |
Wheelbase | 830 mm |
Minimum ground clearance | 88 mm |
Wet weight (including full oil and fuel tank) | 100 kg |
Fuel tank capacity | 5.8 L |
Oil tank capacity | 0.9 L |
